Pride Machine

	Unit	ULTRA LYNX
CAPACITY
Distance between centers	mm	225
Max. turning diameter	mm	200
Max turning length	mm	200
Swing over bed	mm	440
Swing over carriage	mm	180
MAIN SPINDLE
Spindle nose		A2-5
Bore through spindle	mm	53
Bar capacity **	mm	42
Chuck size	mm	200
Front bearing bore	mm	80
SPINDLE DRIVE
Spindle motor power (cont./30 min Rating)	kW	5.5/7.5
Speed range	rpm	50-4000
AXES SLIDES
X axis stroke	mm	120
Rapid traverse x axis	m/min	20
Z axis stroke	mm	200
Rapid traverse z axis	m/min	20
TAILSTOCK
Quill diameter	mm	60
Quill stroke	mm	80
Taper in quill	mm	MT-4
Tailstock body travel	mm	200
TURRET
Turret type	Hydraulic	HTP-63
No. of stations		8
OD turning tool size	mm	25 x 25
Max. boring bar size	mm	40
MISCELLANEOUS
Weight (approx.)	Kg	2200
Dimension L	mm	1950
Dimension W	mm	1400
Dimension H	mm	1700
CNC SYSTEM Std. / Opt.		FANUC / Siemens or Mitsubishi
